High voltage switching diode

 Home  >  Product Center  >  Chip Diodes  >  High voltage switching diode

Series overview

LIZgh-voltage diodes are patented products using alumina ceramic substrates, which have the ability to resist high heat and mechanical stress, suitable for wave soldering and reflow soldering, and suitable for circuit board miniaturization.

yageo_prod_application_icon.png Application
display more
product image Number of channels Spilled power mW Repeatable reverse peak voltage V(Max.) Repeated recovery current mA (Max.) Non-repetitive forward current mA (Max.) Non-repetitive forward current mA (Max.) Forward voltage V(Max.) Forward voltage V(Max.) Leakage current uA(Max.) Capacitance pF(Max.) Reverse recovery time ns(Max.) Package Specifications(PDF)
CDBAV21W CDBAV21W
CDBAV21W
1 400 250 300 500 1000 1.0 1.25 0.1 5 50 CD-1206
CDBAV21WS CDBAV21WS
CDBAV21WS
1 200 250 300 500 1000 1.0 1.25 0.1 5 50 CD-0805
